PROJECTS

These are some of the Projects I have currently in the works...

I am using Rhino's Height field conversion from 2D images to 3D.

Escher's Dragon

MC Escher's Dragon is incredible art work!

This is a Rhino Height field Conversion using a 2D Image it creates a 3D Surface

Escher Dragon in Desk Proto with Tool Path Calculated

This the Escher Dragon Cut on the Pocket NC.
I've yet to machine Argentium Silver without some micro chips fusing into the nooks and crannies while cutting the part. I believe there is lots of hidden detail will come out after bead blast.

Billy Jack Hobo Nickel

Buffalo Nickel with DATE and LIBERTY Mask Outline

Buffalo Nickel Height field Pre MeshTrim in Rhino

Buffalo Nickel Height field with DATE and LIBERTY Rhino MeshTrim applied

Buffalo Nickel Height field with DATE and LIBERTY Ready for CAM

Buffalo Nickel Desk Proto Import ready for Tool Path

Buffalo Nickel Desk Proto Import with Tool Path Calculated

Billy Jack machined on the Pocket NC

Escher's Leaf and Droplette

Escher's Leaf and Droplet

Escher's Leaf & Droplet Rhino Height field Surface

This is the Enamel that I will apply to fill the nooks and crannies. It's going to look quite fresh! Next I'll create the water droplet with a high polish of the silver so it actually reflect back at you but also will be covered in clear enamel like a water drop. Trust this is going to rock it!
